Description
692 36 313RD R Schlage Electronics Exit Device
The 692 SmartBar is an electronic switching device with no moving parts, which serves as a non-latching request-to-exit device. It allows one motion egress at doors equipped with an electronic locking device, most commonly an electromagnetic lock, with âÂÂÃÂìÃÂno prior knowledgeâÂÂÃÂìì required by the user.
- Patent-pending infrared detection along bar releases locking device when light beam is broken
- One motion egress when installed with electromagnetic or electrified locks
- Large "PUSH TO EXIT" lettering provides obvious exit indication with glow-in-the- dark option
- Low profile provides ample clearance through the door
- Audible alarm is standard
- Left- or right-hand reverse (field reversible)
- For aluminum, hollow metal and wood doors
- No moving parts for low maintenance and long life
- Heavy-duty aluminum extrusion with cast metal end caps for maximum durability
- Quick installation brackets/universal mounting system
Schlage Electronics Finishes Chart
