70-KP8276 LNL 26D

The Profile Series are standalone access control products that offer a broad selection of technologies and programming features combined with ANSI/BHMA Grade 1 mechanical locks. Many variations of the products are available. The locks are programmed via infrared data transfer and/or keypad, and all units utilize a battery powered microprocessor based controller with non-volatile memory to preserve user codes. Available in 8200 Series mortise lock, 10-Line cylindrical lock and 80 Series rim and mortise exit device configurations. All products with the keypad feature offer access codes which may vary from 1 to 6 digits and utilize a master code for keypad programming. Various locking modes allow the operation of the lock to be tailored to each opening and individual user, such as panic, adjustable momentary unlock and passage.

• Key outside retracts and projects deadbolt and retracts latchbolt

• Lever inside retracts latchbolt and deadbolt simultaneously when deadbolt is projected

•Lever outside rigid except when in “passage” mode or with valid user credential

• Lever outside locks electrically with deadbolt projected. Master Code & Emergency Code will allow lever outside to retract latchbolt & deadbolt

• Thumb turn retracts and projects deadbolt

• Auxiliary deadlatch
