9500-BSP HES Electric Strike

The 9500 Series is a 3 hour fire rated, surface mounted electric strike designed to accommodate rim exit devices with a 3/4" Pullman latch. All components are completely encased within its 3/4" thick stainless steel housing, so no cutting on the frame is required for installation. Simply place the electric strike on the surface of the frame, align it with the exit latchbolt and install. Adjustments have never been easier as the base is now separate from the cover. The 9500 exceeds grade-1 standards for strength and performance. It is field selectable for fail secure and fail safe operation, and for 12 or 24VDC. This unique electric strike complies with NFPA 80-07 guidelines for retrofit into fire-rated frames.

• UL 10C fire-rated, 3 hour (fail secure)
• CAN4-S104 (ULC-S104) fire door conformant
• WHI fire door listed
• UL 1034 burglary-resistant listed and suitable for outdoor use
• UL 294 (6th Edition) Listed
• ANSI/BHMA A156.31, Grade 1 (#E09371, #E09372, #E09373)
• NFPA-252 fire door conformant
• ASTM-E152 fire door conformant
• California Fire Marshall listed
• NFPA 80-07 compliant
• RoHS compliant
• Patent #6,390,520
• Patent pending
