Description
The Securitron AccuPower AQM20 Series of Multivoltage, supervised switching power supplies come with a battery charger, and provide up to 20 total amps of lowvoltage DC output. These field selectable units contain two (2) power modules with the flexibility for delivering 12 VDC, 24 VDC or 12 and 24 VDC at the same time, with up to 16 independently controlled, power limited outputs. Rated up to 16As continuous output 12 VDC, 8A continuous output at 24 VDC. Tolerates brownout and overvoltage input at +30% to -30% of selected line voltage, either 120 VAC or 240 VAC. Includes thermal shutdown protection with auto restart. Circuit breaker protects against overcurrent and reverse-battery faults. Battery charger and power supervision included. Dedicated voltage enables faster battery charging even under full load. MagnaCare lifetime replacement, no fault warranty. Available with up to 16 Class 2 power limited outputs. Available with configurable access control input/ outputs with fire trigger in either PTC or with fuse/dry contact option, or configurable outputs with fire relay input. 120/240 VAC field selectable AC input. LED indicators and form "C" contacts. Supports up to two (2) 12V or 24V sealed gel, AGM or wet lead acid batteries. Operating temperature is between -4 to +104F [-20 to + 40C].
for supervision
