Description
CL33903 NZD 626 M08 24AD M92 Corbin Russwin Cylindrical Lock
Utilizing the ML2000 Series Grade 1 Mortise Lock with the patented quick reversible latchbolt, the ML20900 Series provides actuator operated remote locking and unlocking. The self contained integral continuous duty aqctuator allows installation in standard mortise prep with slight modification. The ML20900 ECL is ideal for use where increased security is necessary at all times, such as tenant space, pharmacies, computer rooms and high security areas. THe ML20900 Series features Ecoflex Technology, reducing energy consumption up to 96% as certified by GreenCircle. It is field configurable to fail safe or fail secure and operates off 12-24VDC.
- Utilizes the CL3300 Series Cylindrical Lockset with LeverRelease™ Mechanism• Self-contained integral solenoid allows installation in modifiedcylindrical prep
- Minimal power requirements – device is designed to lock orunlock as the situation demands
- Available in either 12 or 24VAC/VDC
- Mechanical cylinder override• Fail Safe and Fail Secure mode available
- Optional M92 Request to Exit (REX) switch
- ElectroLynx® 8-pin connector
