Description
AM300 is a small system for organised online access.
The access master unit is the access management system. It contains all access functions and data. This system is specially designed for branch solutions.
The master unit is equipped with a WEB server and is operated using a WEB browser.
The system is set up, operated and managed using this master unit.
Features
Access controller for up to 8 doors
- 1 AM300 master unit supports 1 - 4 AD500 door units
- Master unit and door units are connected via RS485 bus
- Each door unit supports up to 2 doors
- Clustering of multiple AM300s supports up to 300 control points
- DIN rail assembly 1 AM300 master unit supports 1 - 4 AD500 door units
- Master unit and door units are connected via RS485 bus
- Each door unit supports up to 2 doors
- Clustering of multiple AM300s supports up to 300 control points
- DIN rail assembly
- Software properties
Software properties
- Web-based interface
- Administration using a standard browser
- Manages up to 1,000 users with 1,000 access cards or 500 users with 500 finger templates
- Automatic transfer of the finger template data
- Stores approx. 10,000 system and access events
- REST web service enables complete remote management of the AM300
- Simple backup and restore functions
- Multiple languages supported
