ROFU 8031-002 Magnetic 12/24VDC Shear Lock

Installation Instructions

Specifications

• Holding Force: 2000lbs
• Dimensions: 10.5″ (L) x 1 3/8″W x 1 5/16″ (D)
• Voltage: 12vdc / 24vdc field selectable
• Position Sensor: Dry reed contact and adjustable magnet
• Maximum Gap (between mag and armature plate): 1/8″ or 3mm
• Relock delay: 1-6 Seconds, 3 Seconds is default
• Fail Safe: Releases instantly when power is disconnected
• Fail Alarm: May be released upon activation of fire alarm
• Finish: Magnet and Armature Plate, zinc plated – The housing is black powder coated
• Current draw: Pull In: 1.8A at 12vdc / 1.1A at 24vdc
• Holding 0.5 at 12vdc / 0.32 at 24vdc
• Designed for dual swinging doors
• Can be installed horizontal or vertical
• No residual magnetism
• Limited 36 Month Warranty on this Specialty magnetic lock
