Schlage L9093ELB 03N 626 Electrified Mortise Lock

Grade 1 Fail Safe Electric Mortise Lock, 03 Lever, N Escutcheon, Satin Chromium Plated Finish, Field Reversible

MSRP: $1,768.00
$907.20
You save $860.80
SKU:
L9093ELB 03N 626
In Stock & Ready To Ship!
Current Stock:Only left:

Description

L9090 Series Electrified Mortise Lock

Schlage L Series Overview

Grade 1 Mortise Locks


Proven technology

The L Series is built to withstand the rigors of daily use without fail and is among the most durable, dependable and intelligent family of products on the market today. When you choose a Schlage lock you can have confidence you’ve chosen a solution that will provide protection at the most critical moments.

Comprehensive offering for every opening

Mechanical, wired electrified, wireless electronic and multi-point solutions allow a common aesthetic and consistent user experience throughout the building while lowering the total cost of ownership. And, with an extensive list of functions, keying, trim, levers and finish options the L Series works for any application.

L Mechanical Overview

The Schlage L Series has long been the benchmark for mortise locks. Beyond strength and security – it offers tremendous flexibility to allow it to meet the needs of most every application. The ability to suite across electronic, tubular, exit trim, and multi-point locks allows the Schlage L Series mortise lock to integrate seamlessly into any environment.

L Wired Electrified Overview

The wired electrified L Series is ideal for new construction and high traffic areas where hardwired power ensures continuous operation and where electrified door prep, hinges and wiring can easily be incorporated into the building. The electrified L Series is regularly used as part of an access control system for high security areas, or independently in areas that require a remote access switch.

LE Wireless Electronic Overview

The Schlage LE wireless mortise lock with ENGAGE™ technology is designed to affordably extend electronic access control deeper into the building beyond traditional perimeter and high security openings. The LE is ideal for commercial real estate, K-12, higher education, assisted living, medical offices, or multi-family applications. Facilities can benefit from the enhanced security, efficiency, and convenience of upgrading to electronic credentials


Features

  L9000 Series L400 Series
Chassis
Case Material CRS with zinc dichromate plating
Case Size 4-7/16" x 6-1/16" x 1" (113 mm x 154 mm x 25 mm) 4-7/16" x 3-5/8" x 1" (113 mm x 92 mm x 25 mm)
Case Material Knob or lever to cylinder: 3-7/8" (98 mm); knob or lever to thumbturn hub: 2-11/16" (68 mm)
Door Thickness Standard: 1-3/4" (44 mm)
Optional: 1-3/8" (35 mm) to 2-1/2" (64 mm)
Over 2-1/2" (64 mm) door ranges vary by function. Specify door thickness if other than 1-3/4" and position in door EE, EI, EO, ED
Standard: 1-3/4" (44 mm)
Optional: 1-3/8" (35 mm) to 2-1/2" (64 mm)
Over 2-1/2" (64 mm) door ranges vary by function. Specify door thickness if other than 1-3/4" and position in door EE, EI, EO, ED
Handing Field-reversible without disassembly Non-handed
Trim
Levers/Knobs 33 lever designs: Forged brass or bronze and cast stainless steel
Two knob designs: Heavy-duty wrought brass, bronze or stainless steel
Ligature resistant lever (SL1) and knob (SK1)
HL6 hospital latch (available on 9010 and 9040 functions only)
Tactile warning applied to outside lever; available on 01, 02, 03, 05, 06, 07, 12, 17, 18, M51, M52, M81, ME1, ME2, ME3 lever designs
Roses/Escutcheons L escutcheons: 7-15/16" x 1-3/4" x 7/16" (202 mm x 44 mm x 11 mm); cold-forged brass or bronze and stainless steel
N escutcheons: 7-7/8" x 2-1/2" x 7/16" (200 mm x 64 mm x 11 mm); heavy wrought reinforced brass, bronze and stainless steel
Roses: A ,B ,C: wrought brass or bronze and stainless steel; AVA and MER: forged brass
Finishes 14 available: 605, 606, 609, 612, 613, 619, 622, 625, 626, 626AM, 629, 630, 630AM, 643e
Combinations Available with knob both sides, lever both sides, or knob/lever combinations. Roses cannot be combined with escutcheons.
Latches
Armor Standard: 1-1/4" x 8" x 7/32" (32 mm x 203 mm x 6 mm)
Optional: 1-1/16" x 8" x 7/32" (27 mm x 203 mm x 6 mm)
1-1/4" x 5-9/16" x 7/32" (32 mm x 141 mm x 6 mm)
Bolt 1" (25 mm) throw stainless steel deadbolt
3/4" (19 mm) throw stainless steel latch with anti-friction tongue
Strike Standard: ANSI curved lip strike
1-1/4" x 4-7/8" (32 mm x 124 mm) x 1-3/16"
(30 mm) lip to center with dust box
Optional: Extended lip strike options (7/8", 1", 1-1/2", 1-3/4", 2")
Standard: 1-1/8" x 3-1/2"
(29 mm x 89 mm) with dust box
Optional: 1-1/4" x 4-7/8"
(32 mm x 124 mm) with dust box

Certification/Compliance

  L9000 Series L400 Series
ANSI/BHMA A156.13-2017 Series 1000, Grade 1 Operational and Security
With FSIC interchangeable core cylinders: Grade 2 Security
With SFIC interchangeable core cylinders: Grade 3 Security
ASTM F476-76 Grade 40
ANSI/BHMA A156.36 Grade 1
ICC Complies with ICC A117.1 Accessible and Usable Buildings and Facilities
UL/cUL UL 10C and CAN/ULC-S104 3-hour Fire Listed
All locks listed for A label single doors, 4' x 10' and pairs 8' x 10'
Letter F and UL symbol on latch front indicate listing
Electrified functions are UL/ULC Listed for single-point locking applications
UL 437 Listed when using UL 437 cylinder
UL Listed for 3-hour fire door (except L9076 and L9077)
CA Fire Code All levers with a return to door of 1/2" (64 mm) or less comply
(Formerly Title 19, California State Fire Marshal Standard)
FL Building Code Miami-Dade NOA's and Florida Building Commission Listings
Tornado
