Description
Mortise UnLatch® Strike
Mortise UnLatch is for any application where an electric strike would be used for a mortise type lock. The Mortise UnLatch includes field adjustability for latch and deadlatch positions, releases under pressure and includes a latch status monitoring output.
Features
- No cutting or altering of the jamb required
- Releases under preload
- Fits standard ANSI 4-7/8" strike cutout
- Motorized, no solenoids
- Fully concealed installation
- Maintains dead-latch function at all times
- Continuous duty
- Latch status sensor is standard
- One model works with most North American Mortise Locks (Sargent 7800 and 8200 require tab kit model #STK-1 for retrofit installations)
Specifications
- UL10B Listed
- UL10C Listed
- UL listed to ANSI/SDI-BHMA A250.13 (60PSI) Windstorm
- Patent Numbers: 6,022,056; 6,581,991; 6,902,214
- 24VDC: 40mA continuous, minimum 500mA when operating
- Holding Force: 1500lbs [680kg]
- Operating Temperature: -20 to +125F [-29 to +52C]
- Finish Available: 626 Stainless Steel
